Heat Exchanger Manufacturer

• Color
• Silver

• Condition
• New

• Product Type
• Heat Exchanger

• Size
• Customized

• Structure
• tube Heat Exchanger

• Temperature
• 1 Celsius (oC)

• Usage
• Industrial

• Width
• as per required Meter (m)

• Condition
• New

• Diameter
• 325 mm

• Dimensions
• 2100 mm x 800 mm x 950 mm

• Liquid Flow Rate
• 1200 LPH

• Max Pressure
• 12 bar

• Max. Capacity
• 1500 LPH

• Number of Pipe
• 38 tubes

• Power
• 15 kW

• Structure
• Other, Shell and Tube

• Thickness
• 8 mm

• Voltage
• 415 V

• Weight
• 450 kg

• Working Presssure
• 10 bar

• Color
• Silver

• Condition
• New

• Product Type
• Heat Exchanger

• Size
• Customized

• Structure
• tube Heat Exchanger

• Temperature
• 1 Fahrenheit (oF)

• Usage
• Industrial

• Weight
• as per required Liter (Ltr)

• Width
• as per required Meter (m)

• Air Volume
• 2200 m3/hr

• Condition
• New

• Diameter
• 32 mm tube diameter

• Dimensions
• 1200 mm x 1000 mm x 350 mm

• Liquid Flow Rate
• 1500 LPH

• Max Pressure
• 7 bar

• Max. Capacity
• Up to 4 tons/hr paddy

• Number of Pipe
• 24 tubes

• Power
• No electrical power required (heat transfer only)

• Structure
• Other, Rectangular Finned Heat Exchanger

• Temperature
• Other, Up to 180C

• Thickness
• 5 mm (finned tube wall)

• Weight
• 200 kg

• Working Presssure
• 5 bar

• Air Volume
• Up to 15,000 m3/hr

• Condition
• New

• Diameter
• Tube diameter: 12-25 mm

• Dimensions
• Custom/Standard - Example 1200mm x 900mm x 400mm

• Liquid Flow Rate
• 800-4000 LPH (Liters per hour)

• Max Pressure
• 15 bar

• Max. Capacity
• Up to 100,000 kcal/hr (varies on design)

• Number of Pipe
• Typically 4-8 rows

• Power
• N/A (Steam Operated)

• Structure
• Other, Tube & Fin Multi-Pass Exchanger

• Temperature
• Other, Maximum outlet temp. up to 180C

• Thickness
• Sheet thickness: 1.5-2.5 mm

• Weight
• Approximately 40-150 kg (varies with design)

• Working Presssure
• 3-15 bar

• Air Volume
• N/A (designed for oil-to-oil or oil-to-water exchange)

• Condition
• New

• Diameter
• Tube outer diameter: 20 mm - 25 mm

• Dimensions
• 1000 mm x 400 mm x 300 mm (example, as per standard size)

• Liquid Flow Rate
• 50 - 500 LPH (Liters per hour)

• Max Pressure
• 10 bar

• Max. Capacity
• 100 kW (example - varies as per design)

• Number of Pipe
• 8 - 12 tubes (varies by size/model)

• Power
• Not Applicable (Passive Device)

• Structure
• Other, Fin and tube type, rectangular casing

• Thickness
• 2 mm - 3 mm (tube wall thickness)

• Voltage
• Not Applicable (No electrical input required)

• Weight
• Approximately 30-60 kg (varies by model)

• Working Presssure
• Up to 10 bar
